IN ADDITION TO ALL THE BENEFITS OF THE NEW R410A, COMPATIBLE HEATING AND COOLING SYSTEMS OFFER CONSUMERS, R410A ITSELF SAVES YOU MONEY.
| ♦ | MODEL |
| Indoor: PAC-Z160C-D43 | |
| Outdoor: PSC-Z160C-D43 | |
| ♦ | Type: Cooling Only |
| ♦ | Capacity: 60,000 Btu/h |
| ♦ | Current: 21A |
| ♦ | Rated Current: 31.0A |
| ♦ | Power Input: 4650W |
| ♦ | Indoor Air Volume: 2100mꝪ/H |
| ♦ | MAX. PRESSURE |
| Discharge: 4.5MPa | |
| Suction: 1.9MPa | |
| ♦ | NOISE |
| Indoor: 55dB(A) | |
| Outdoor: 63dB(A) | |
| ♦ | WEIGHT |
| Indoor: 60Kg | |
| Outdoor: 110Kg | |
| ♦ | Rated Voltage: 230V |
| ♦ | Rated Frequency: 60Hz |
| ♦ | Refrigerant/Charge: R410A/3.950Kg |
| ♦ | Outdoor Unit Waterproof Protection: IPX4Specification |
| ♦ | Model: PAC-Z93C-D43 |
| ♦ | HP: 36000 |
| ♦ | EER (W/W): 2.72 |
| ♦ | Refrigerant Type / Charge: R410A／3000g |
| ♦ | Power Supply: 230V/60HZ/1P |
| ♦ | Application Area (SQM): 50~70 NET |
| ♦ | DIMENSION (W X H X D) |
| Indoor (mm): 1775×540×415 | |
| Outdoor (mm): 900×360×805 | |
| ♦ | NET WEIGHT |
| Indoor (kg): 52 | |
| Outdoor (kg): 70 |
